OK40 Plastic Heavy Serie with AL
There are many cable carrier systems produced by Tacflex Cable Carrier Systems. These systems can easily find the desired product with the material used, length, width, or categorized according to the intended use of the product.
| Bending Radius | 75 | 100 | 125 | 150 | 200 | 250 | 300 |
| H (mm) | 72 | 72 | 72 | 72 | 72 | 72 | 72 |
| X (mm) | 212 | 262 | 312 | 362 | 462 | 562 | 662 |
| Y (mm) | 236 | 314 | 392 | 471 | 628 | 785 | 942 |
OK40 AL SERIE
Aluminium , Plastic Heavy Serie with AL
| OK40 AL | A | B | C | D | R | W |
| MODEL | Inner Height (mm) | Inner Lenght (mm) | Outter Height (mm) | Outter Lenght (mm) | Bending Radius | Weight Kg/Mt |
|---|---|---|---|---|---|---|
| OK40 AL 250 R ... | 40 | 250 | 62 | 278 | 75, 100, 125, 150, 200, 250 , 300 | 3,552 |
| OK40 AL 300 R ... | 40 | 300 | 62 | 328 | 75, 100, 125, 150, 200, 250 , 300 | 3,388 |
| OK40 AL 400 R ... | 40 | 400 | 62 | 428 | 75, 100, 125, 150, 200, 250 , 300 | 4,56 |
| OK40 AL 500 R ... | 40 | 500 | 62 | 528 | 75, 100, 125, 150, 200, 250 , 300 | 5,232 |
